LPG

Vapour eliminators to extract vapour from LPG dispensing system

Vapour eliminators are complimentary devices to flow meters as they extract accumulated air and vapour which enhances the accuracy of the meters. They are commonly installed upstream of a meter in a liquid dispensing system and piped to storage tanks for extracted vapours to be deposited to.

Product description

Eliminating vapour in liquid dispensing systems is desirable as vapours provide false readings which consequently leads to the consumer paying for more than what they have received.

icon 3 squares in front of eachother symbolising material

Material

Body: Stainless steel

icon a gear with lines going up down left and right symbolising specifications

Specifications

Gas types: LPG (Propane, Butane), NH3 (Ammonia, Anhydrous Ammonia), Kerosene, BioLPG, gasoline, diesel, DME, cryogenics
Connections: Thread, flange, weld
Type: NPT, ANSI, DIN, BUTT
Pressure range: Up to 400 bar (5,800 psi)
Temperature range: -196˚C to +450˚C (-320.8˚F to +842˚F)
Sizes and range: ½" to 1" (NPT/butt), ½" to 4" (ANSI), DN10 to DN100 (DIN)
Series: BNA model
Standards: CE-ATEX

*Materials and specifications are subject to generalisation. Our experienced people are ready to help you find the correct fit for your application.

icon a magnifying glass over a gear symbolising features

Features

  • Robust design for a long-life span
  • Fail-safe magnetic display without a power supply
  • Explosion-proof versions available
  • Corrosion-resistant
  • Level measurement independent of media changes
  • Interface-layer level measurement from a density 100 kg/m3

Did you know?

Optional mounting of level transmitters and magnetic switches possible upon request

We can provide customised solutions upon request

The indicators can be supplied in other corrosion resistant materials
