Automatic changeover valve for cryogenic gas

Product description

The changeover works on differential pressure with the automatic switch between cylinders happening when pressure drops below a pre-set minimal. A visual indicator shows the release of the pressure switch and the changeover 'reserve' cylinder.

icon 3 squares in front of eachother symbolising material

Material

Body: Brass
Bonnet: Brass
Seat disc: Viton
Diaphragm: Aluminium
Bonnet spring: Steel
Back-cap spring: Stainless steel

icon a gear with lines going up down left and right symbolising specifications

Specifications

Gas types: LNG (Liquefied Natural Gas) and cryogenics
Connections: Thread
Type: NPT (CGA)
Pressure range: Max. 2.1 to 202 bar (30.4 to 3,000 psi)
Sizes and range: 1/4"
Series available: M2523HP Series
Standards: PED, ASME, CRN

*Materials and specifications are subject to generalisation. Our experienced people are ready to help you find the correct fit for your application.

icon a magnifying glass over a gear symbolising features

Features

  • Nickle plated
  • 100% factory tested
  • Cleaned for oxygen service per CGA G-4.1
  • Porous bronze filter to limit particles from entering
  • Positive shut-off during flow reversal
  • Provided with mounting bracket and pressure adjustment wrench
  • Factory set at 50 PSI on service side
  • Pressure gauge

Did you know?

ProSupply also offers CGA Connection: 320, 326, 350, 540, 580 and 590

Automatic changeovers are also available for LPG and CO2 service with different materials
