LPG

Electrical vaporizers for optimal LPG consumption

Dry-electric vaporizers are designed to provide a constant gas vapour supply with 100% utilisation of tank content while maintaining the desired propane/butane composition. These small capacity vaporizers are suitable for commercial, residential and light industrial LPG applications.

Product description

Dry-electric vaporizers are purely electrical devices that require no water to run and are impossible to overheat. Essentially, they are boilers that do not build pressure: liquid enters and vapour exits.

Material

All parts are LPG compatible.

More information can be provided upon request.

Specifications

Gas types: LPG (Propane, Butane)
Connections: Thread
Type: NPT
Pressure range: Up to 25 bar (362.5 psi)
Capacity: 25 to 320 kg/h
Sizes and range: ½" to 3/4"
Standards: CE, PED, ATEX, UL, DEMCO

*Materials and specifications are subject to generalisation. Our experienced people are ready to help you find the correct fit for your application.

Features

Dry-electric design
High reliability
Robust controls
Thermocouple temperature sensor
Energy-efficient, self-modulating heaters
Easy installation with multiple mounting options
Accessibility to all components requiring maintenance
Corrosion free
Quick start in less than 60 sec. for fast provision of LPG vapour
98% thermal efficiency
Can operate on pure Propane or Butane
Continuous service during power interruptions

Did you know?

The vaporizer is available with 1 or 3 phase electrical power supply

Some versions have heavy-duty contactors that increase the life-span and reduces maintenance

If larger capacities are required, the vaporizers pair perfectly together to meet requirements
