Reels for keeping LPG hoses organised

Hose reels are created specifically for fuel delivery and hose dependent applications to keep the hoses organised and ensure quick pick-up and deployment at filling cylinders, fuelling vehicles, dispensing systems and home delivery vehicles.

Product description

Keeping hoses off the ground prolongs their life cycle as it reduces wear and tear and ensures external rupturing being mitigated. The reels are great for protecting the hoses between usage by maintaining them in order off the ground. The reels can be configured to fit customer specific applications.

icon 3 squares in front of eachother symbolising material


Construction: Steel (painted graphite), aluminium, stainless steel

icon a gear with lines going up down left and right symbolising specifications


Gas types: LPG (Propane, Butane)
Connections: Thread
Types: NPT
Pressure range: 24 bar (350 psi)
Temperature range: -40˚C to +177˚C (-40˚F to +350˚F)
Sizes and ranges: ½" to 1½" (hose diameter)
Series available: PB/DPB, PBGMB/PBGMT, PBM, SPBN800 and SPB800
Standards: UL/EX-Proof (electric motors), ATEX (Air motors)

*Materials and specifications are subject to generalisation. Our experienced people are ready to help you find the correct fit for your application.

icon a magnifying glass over a gear symbolising features


  • Non-sparking ratchet assemblies
  • Explosion-proof motors
  • Suspended IV reels that allow access on either side of the vehicle
  • Standard inlet: 90˚ ball bearing swivel joint, 1-1/2" female NPT threads
  • Versatile mounting opportunities
  • Material: Aluminium, stainless steel, e-coated and painted steel
  • Contamination and corrosion protected
  • Easy maintenance

Did you know?

We provide complete autogas station packages that do not compromise with safety

Skid units are available

MAKEEN Gas Equipment can provide different hose and nozzle configurations: single (1) hose and nozzle, dual (2) hoses and nozzles or quadruple (4) hoses/nozzles
