Horizontal compressors are used for transfers of liquefied gas from one vessel to another by forcing the media through a pressure increase in the gas phase with following vapour recovery to maximise the transferred volume. They are used in bulk transfers, barge and rail loading and unloading, pressure boosting and many more.
As the capacity of a vertical compressor may not always be sufficient for all tasks, the horizontal compressor is the ultimate alternative as it provides the largest liquid transfer capacity.
Body: Ductile iron
Cylinders: Ductile iron
Pistons: Steel, aluminium
Retainer rings: Carbon steel
Main bearings: Tapered roller
Valve seat: Stainless steel
O-rings: Buna-N, PTFE, Viton, Neoprene
Gas types: LPG (Propane, Butane), NH3 (Ammonia, Anhydrous Ammonia), NG (Natural gas), Biogas, CO2 (Carbon dioxide), DME (Dimethyl Ether), refrigerants
Connections: Flange
Type: ANSI, slip-on
Pressure range: Up to 113.8 bar (1,650 psi)
Flow rate: Max. 704 m3/h (414 cfm)
Brake horsepower: 75 HP (55.9 kW)
Temperature outlet: +177˚C (+350˚F)
Sizes and range: 1½" to 3" (ANSI), 2" to 3" (slip-on)
Series available: NGH series, HG series and THG series
Standards: UL-listed, EU
*Materials and specifications are subject to generalisation. Our experienced people are ready to help you find the correct fit for your application.
